Hydraulic Detachable Gooseneck

TrailKing
Trailers

Find Your Nearest Location

Find Location

Your Preferred Store

Change location Change location

For more than two decades, our Hydraulic Detachable Gooseneck Trailer has been North America’s bestselling detachable lowboy for construction professionals—and for good reason. It’s engineered to make unhooking, loading and unloading, and hooking up again a simple one-person operation. Its dependable load-hauling strength, durability, and versatility can stand up to any challenge, including “tough to scale” loads.

Features
Documents

+ Expand All
- Close All

Specifications

TKHDG-C STANDARD EQUIPMENT	TK70HDG	TK102HDG	TK110HDG
Capacity {in 12’}	70,000 lbs	102,000 lbs.	110,000 lbs.
10’10” gooseneck (14” KP setting with 86” swing clearance)	X	X	-
12’10” gooseneck (14” KP setting with 11” swing clearance)	-	_	X
2^nd king pin setting (38” KP setting with 86” swing clearance)	-	-	X
Deck Length	24’	25’9”	25’9”
1 ½ ” Oak decking (raised) (NEI)	X	-`	-
1 ¾” apitong decking (raised) (NET)	-	X	X
25,000 lb. (5/8” wall) axles	2	3	3
3^rd axle air lift	-	X	X
Axle spacing	50”	55”	55”
Anti-lock brake system	X	-	-
Frame reinforced for single axle booster or flip axle	-	-	X
50” loaded 5^th wheel height	X	X	X
Zinc-rich primer and polyurethane topcoat	X	X	X
