  • Innovative diesel-electric drive concept - impressive performance with the best possible consumption values

    The crushing plants are equipped with efficient, powerful diesel-electric drives. They ensure environmentally friendly operation combined with low fuel consumption.

    Efficient and powerful diesel-electric drive (A) for low fuel consumption (crusher and all conveyor belts are driven electrically)

    External power supply (B) for even more economic application in quarries

  • Jaw crusher

    Jaw crushers operate according to the principle of pressure crushing. The crushed material is crushed in the wedge-shaped pit between the fixed crusher jaw and the crusher jaw articulated on an eccentric shaft. The material is crushed by the elliptic course of movement and falls down due to gravity. This occurs until the material is smaller than the set crushing gap.

  • Continuous Feed System (CFS)

    Uniform loading is indispensable for a good product, optimum throughput and low wear.

    To ensure that the crushing chamber is always evenly filled, the Continuous Feed System (CFS) monitors the crusher level (jaw crusher and cone crusher) or the load at the rocker and rotor as well as the motor utilization (impact crusher).

    Independently of this, the CFS regulates the frequency of the vibrating feeder and prescreen. A backlog on the prescreen is thus avoided and crusher utilization is optimized. When the crushing chamber is free again after overloading, material transport is continued without a delay.

    The CFS facilitates the work of the operator because the machine automatically guarantees a homogeneous material flow, thus ensuring optimum loading of the crusher.

CRUSHER

Crusher drive type electric
Crusher weight (approx.) 108,000 lbs
Gap width max. 10 in
Single toggle jaw crusher type STR115-100
Crusher inlet width 49 in
Gap width min. 3.1 in
Crusher inlet (W x D) 1,250 mm x 1,000 mm
Crusher capacity 268 hp
Crusher gap adjustment Hydraulically supported
