MR 170 PRO

  • Kleemann
  • Mobile Impact Crushers

Find Your Nearest Location

Your Preferred Store
Change location Change location
Request Quote
Key Features & Specs

Properties

Classic stone crushing plant, which, primarily used in limestone, is equally suited as a primary crusher for feed sizes of up to 1300 mm (with crusher SHH 17/100) and with a correspondingly reduced feed size for crushing final grains (with crusher SHB 17/100). The electric crusher drive can be operated either via the on-board generator or a stationary power supply. The effective primary screening by the large double-deck prescreen contributes to the high feed capacity, which is very important for processing contaminated feed material.

  • Extremely robust design
  • Frequency-controlled vibrating feeder
  • PLC control system with LCD display
  • Independently vibrating double-deck prescreen
  • + Expand All
  • - Close All
  • Impact crusher

    In contrast to pressure crushing, the impact crusher operates according to the impact crushing principle. In this process, the crushed material is picked up by a fast moving rotor, greatly accelerated and smashed against a fixed impact plate ("impact toggles"). From there, it falls back within range of the rotor. The crushed material is broken again and again until it can pass through the gap between the rotor and impact toggle.

  • Effective prescreening - better results and less wear

    For effective prescreening of the feed material, the crushing plants are equipped with an independently vibrating double-deck prescreen. Wear in the crushing chamber is thus reduced by diverting the medium grain directly onto the vibrating extractor. The screen surfaces in the upper and lower deck can be changed easily and safely.

  • Innovative diesel-electric drive concept - impressive performance with the best possible consumption values

    The crushing plants are equipped with efficient, powerful diesel-electric drives. They ensure environmentally friendly operation combined with low fuel consumption.

    Efficient and powerful diesel-electric drive (A) for low fuel consumption (crusher and all conveyor belts are driven electrically)

    External power supply (B) for even more economic application in quarries

CRUSHER

Crusher drive type electric
Type of impact toggle adjustment stepless, fully hydraulic
Crusher inlet (W x H) 65 in x 40 in
Rotor diameter 52 in
Crusher weight (approx.) 1,102 lbs
Crusher inlet width 65 in
Crusher capacity 476 hp
